3500 Single-Hung Window

The 3500 Single-Hung Window is one of MI’s best vinyl windows. This vinyl single-hung window offers handcrafted quality, exceptional durability, and optimal energy efficiency. With standard features that include a pre-punched mounting fin and removable sash for easy drywall pass through, our 3500 window is ideal for any new home construction project. A full-length lift rail and metal reinforcements at the meeting rail provide aesthetic and performance benefits that complement the window’s builder-friendly attributes.

Features

• Warm-edge spacer system maximizes energy efficiency and improves seal performance of insulated glass units
• Welded, multi-chambered frame and sash for superior strength and energy-efficiency
• Integral J-Channel and mounting fin with pre-punched holes for easy and efficient installations
• Top glass is drop-in tape glazed for easy material pass through
• Heavy-duty weatherstripping for protection against wind, rain, dust, and noise

Product Details

• Multi-chamber mainframe design
• 2-7/8” frame depth
• 3/4” insulating glass
• 4-9/16”, 6-9/16”, and 7-9/16” wood extension jambs available
• Continuous head and sill mulling for twins and triples
• Brickmould available

Performance Ratings

• STC: 28
• U-Value: 0.30-0.47
• SHGC: 0.20-0.64
• VLT: 0.39-0.66

Glass Options

• Low-E
• HP Low-E
• Tempered
• Obscure
• Rain
• Argon gas enhanced

Grid Options

• 5/8” flat grids-between-the-glass
• 3/4” flat grids-between-the-glass (Southern Region only)
• 7/8” flat grids-between-the-glass (Eastern Region only)
• 11/16” sculptured grids-between-the-glass
• 15/16” sculptured grids-between-the-glass (Eastern Region only)
• 1-1/8” simulated divided light (Southern Region only)

Hardware

• Color match
• Recessed tilt latch
• Surface-mounted tilt latch available (3500HP)
• Optional window operating control device (WOCD)
